OT600 Portable Pump Suction Type 6 in1 Gas Detector

Home > Products
OT600 Portable Pump Suction Type 6 in1 Gas Detector

OT600 Portable Pump Suction Type 6 in1 Gas Detector

Monitor 1–6 selected gases with OT600, or ask about a custom seven-gas configuration.

  • Reach the location to be tested

    The built-in pump and optional external pump or probe accessories support the sampling arrangement specified for the site.

  • Make the reading useful in the field

    A color display and sound, light and vibration warnings help the operator follow changing concentrations.

  • Keep a usable record

    On-device storage and configurable alarm setpoints support review and site-specific use.

IP66 protection class. Confirm the supplied gas count, sensors, sampling accessories and storage requirements. Built-in pump / optional external pump.

Request a Quote WhatsApp

Overview

The OT600 series is an industrial-grade, highly sensitive portable multi-gas detection instrument. It is designed for use in explosion-proof environments for gas leak emergency response, as well as in underground pipelines and mines. This device effectively ensures the safety of personnel and prevents damage to production equipment. The product features a rubber-coated design for a comfortable feel. It primarily measures gas leakage concentrations and can detect various gases depending on the sensor type. The compact size, ease of operation, portability, and excellent shock resistance make it ideal for various applications. A built-in pump is supplied; an external pump is optional. The product uses high-resolution color LCD technology, providing a clear and intuitive display.

Key Features

Gas Configuration & Sampling

  • Simultaneous detection of 1-6 gases, with arbitrary sensor combinations.
  • Customizable for simultaneous detection of 7 gases.
  • Optional sampling probe and guide tube.
  • Built-in high-power carbon film self-priming pump for extremely fast response time.
  • Wide Gas Selection
  • Pumped Sampling & Fast Response
  • Optional external pump for the sampling configuration

Alarms & Worker Safety

  • Triple Alarm (Audible, Visual, Vibration)
  • Customizable Alarm Setpoints
  • Multiple Alarm Modes (High/Low, TWA, STEL)

Records & Connectivity

  • Alarm Record Storage
  • Data storage capability, storing up to 10,000 data entries.
  • Customizable PC Data Upload

Display & Calibration

  • Featuring a 2.4-inch high-definition full-color IPS industrial screen with excellent viewing angle.

Power & Protection

  • Dustproof, explosion-proof, and waterproof design.
  • Intrinsically safe circuit design, resistant to static electricity and electromagnetic interference.
  • Standby Time ≥ 8 Hours
  • Intrinsically Safe & Superior Explosion-Proof
  • IP66 Waterproof & Dustproof

Field Options & Customization

  • High Sensitivity & Stable Reliability
  • Ergonomic design for Asian users, offering a comfortable grip.
  • OEM & ODM & OBM：

Technical Specifications

Detection Method  Built-in pump / optional external pump
Suitable Gases  Combustible/Toxic/Hazardous gases/Oxygen, etc.
Detection Principle  Catalysis, electrochemistry, PID, infrared, laser, semiconductor, etc.
Response Time  ≤30s
Display Error  ±5% FS
Indication Method:  LCD displays real-time data and system status; LED, sound, vibration indicators, alarms, fault and undervoltage indicators.
Operating Voltage  DC3.7V
Battery Capacity  1800mAh + 1300mAh Lithium-ion rechargeable battery
Charging Time  ≤6h
Operating Time  ≥8h continuous (non-alarm standby mode)
Explosion-proof Certificate Number  CNEx23.1392X
Explosion-proof Mark  Ex ia ⅡC T4 Ga/Ex ia ⅢC T200 130℃ Da
Protection Rating  IP66
Dimensions  165mm × 80mm × 42mm (L × W × H)
Weight  Approx. 450g

Videos

Available Gases & Detection Ranges

The gases and ranges below are configuration options. OT600 Portable Pump Suction Type 6 in1 Gas Detector; confirm the final sensor combination and ranges with our team.

Common Gas Parameter listing
Gas detected Measuring Range Optional Range Resolution Rat Response Time
LEL -combustible gas 0-100%LEL 0-100%VOL (Infrared or catalytic ) 1%LEL/1%vol ≤10s
carbon monoxide 0-1000PPm 0-500/2000/5000PPm 0.1/1PPm ≤10s
TVOC 0-100PPM 0-100PPM 0.1PPm/1PPM ≤15s
hydrogen 0-100%LEL 0-1000PPM 1%LEL/1PPM ≤15s
natural gas 0-100%LEL 0-100%LEL 1%LEL ≤10s
Oxygen-O2 0-30%VOL 0-30%、0-100%VOL 0.1%vol ≤10s
ozone 0-10PPm 0-20、100PPm 0.01PPm/0.1PPM ≤15s
hydrogen sulfide-H2S 0-100PPm 0-50、200、1000PPm 1/0.1PPm ≤10s
Methane-CH4 0-100%LEL 0-100%VOL 1%LEL/1%vol ≤10s
fluorine 0-10PM 0-1、10PPM 1/0.1PPm ≤15s
hydrogen chloride 0-20PPm 0-20/50PPm/100PPM 0.01/0.1PPm ≤15s
Nitrogen-N2 0-30%VOL 0-30%VOL、100%VOL 0.1%LEL/1PPM ≤10s
hydrogen 0-100%LEL 0-1000PPm 1%LEL/0.1PPm ≤15s
chlorine 0-20PPm 0-10、100PPm 0.1PPm ≤15s
ammonia gas 0-100PPm 0-50、500、1000PPm 1/0.1PPm ≤15s
oxynitride 0-20PPm 0-50、1000PPm 0.1/1PPm ≤15s
methanal 0-20PPm 0-50、100PPm 1/0.1PPm ≤15s
sulfur dioxide 0-20PPm 0-50、1000PPm 0.1/1PPm ≤15s
nitric oxide 0-250PPm 0-500、1000PPm 1PPm ≤15s
nitrogen oxide 0-20PPm 0-50、1000PPm 0.1/1PPm ≤15s
phosphine 0-20PPm 0-20、100PPm 0.1PPm ≤15s
acrylonitrile 0-100PPM 0-100PPm 0.1/1PPm ≤15s
carbon dioxide 0-5000PPm 0-1%/5%/10%VOL(Infrared ) 1PPM/0.01%VOL ≤15s
hydrogen fluoride 0-10PPm 0-1、10、50、100PPM 0.01/0.1PPm ≤15s
Xylene/methylbenzene 0-20PPm 0-5、10、50、100PPm 0.01/0.1PPm ≤15s
oxirane 0-100PPm 0-100PPm 1/0.1PPm ≤15s
For other gases and measuring ranges, please contact us directly!
Note: Not all gases and range are listed, if you need more information, please contact us.
