Carry a compact laser methane detector for routine walk-through inspections.
Inspect accessible methane-related equipment from a suitable stand-off point.
On-device readings and sound/light alarms help guide a closer check.
The compact form supports one-person field inspection.
Confirm the display, measurement distance and target conditions for the exact supplied version.
G6000AS handheld laser gas remote meter consists of optical-mechanical system, signal processing system, display and alarm system and shell components. Mainly used for long-distance measurement of the concentration of methane or methane-containing gases (natural gas, gas or similar gases). The telemeter emits a beam of infrared laser to the detection point, which can quickly measure the air mass concentration between the detection point and the telemeter. For the convenience of observation, the remote sensor also emits a visible green laser to the detection point. This telemeter can detect the methane concentration value of the checked location in real time and accurately, and display it. When the alarm value is exceeded, it will give an audible and visual alarm to facilitate personnel to make subsequent actions.
| Detection range | 0~10000/50000/100000 ppm·m (three levels optional, default 50000) |
| Detection distance | 50m, 80m, 100m |
| Minimum detection limit | 5ppm·m Accuracy:±10%FS |
| Response time | 0.1s |
| Continuous working time | 8h |
| Power supply mode | lithium battery |
| Display mode | 1.1-inch monochrome OLED |
| Alarm display | alarm light (red) lights up |
| Alarm volume | ≥70dB (at 1 meter) |
| Explosion-proof certificate number | CNEx22.7675X |
| Explosion-proof mark | Ex ib ⅡB T4 Gb/Ex ib ⅢC T130℃ Db |
| Protection level | IP67 Ambient |
| temperature | (-20～50)℃ |
| Environmental humidity | (10~93)%RH, no condensation |
| Battery voltage | DC 7.4V |
| Battery capacity | 2800mAh |
| Product size | 206.3*62*89.8mm (with scope) 206.3*62*62mm (without scope) Product net weight:650g |
Tell us the survey route, target distance and surface, reporting needs and quantity.
